Raven SmarTrax Supplement Installation Manual

Manual # 016-0190-074 Rev B 06/07
17
C HAPTER
S TART -U P P ROCEDURES
After installing the SmarTrax on your machine, always follow these start-up
procedures.
• Make sure the Steering Position Sensor does not over-extend or over-compress
when turning the wheels.
• Turn the wheels fully from side to side numerous times to remove air from the
hydraulic system.
• Time the wheels for full left to right and right to left time of approximately 6
seconds. Refer to the Universal Kit Manual for instructions on this.
• Adjust the pressure switch to the most responsive setting. Refer to the
Universal Kit Manual for instructions on this.
