Raven Switch Pro - Appendix B System Diagrams; Switch Pro for SCS 440;450 Cabled Systems

APPENDIX
B
: 11
APPE NDIX B SYSTEM DIAGRAMS
The following system diagrams may be helpful during installation or to troubleshoot the Switch Pro system. Be
sure to locate the appropriate system diagram for the Switch Pro system currently installed.
SWITCH PRO FOR SCS 440/450 CABLED SYSTEMS
The following diagrams illustrate connections for the Switch Pro interface cable (P/N 115-0171-803) included with
the 117-0171-167 kits.
