SEE FIG. 28
Follow instructions in section BURNER ACCESS, Steps 1
to 3 and BURNER REMOVAL.
1. Isolate fuel supply.
2. Disconnect flexible hose (This must be replaced
annually).
3. Remove solenoid plug.
4. Remove feed pipe.
5. Slacken three securing screws and remove pump.
6. Check drive, replace if worn or damaged.
7. Replace pump, re-assemble in reverse order.
Replacement of parts (Burner)
PUMP ACCESS
Fig. 28 DESN 515976
20
PUMP
