65
RAYCO
®
RG 1635A STUMP CUTTER
PARTS
ITEM # PART# DESCRIPTION QTY. INCLUDED IN
1 6809 MAIN FRAME WELDMENT 1
2 4925 CUTTING BOOM 1
3 7047 PIVOT HEAD 1
730089 BUSHING - 1.5 x 1 x 1 1
4 2116 HINGE PIN 1
5 724916 SLOTTED NUT - 1 1/2". 1
6 728005 COTTER PIN 1
7 4404 KING PIN 1
8 750448 BEARING - SPHERICAL - 1 3/4" 2
9 OUTER RACE 2
10 750449 WASHER - PIVOT 1
11 4405 LOCK PLATE 1
12 4690 PRE-LOAD NUT 1
13 722502 BOLT - 1/2" - 13 x 1" 1
14 726502 LOCK WASHER - 1/2" 1
15 750413 WHIZ BOLT - 1/2" - 16 x 1 1/4" 1
16 730025 PLASTIC COATED CLAMP 1
17 722303 HEX HEAD BOLT - 3/8 - 16 3
18 724301 HEX NUT - 3/8 - 16 3
19 726302 LOCK WASHER - 3/8" 3
20 4978 TELESCOPING CYLINDER LOOP 1
21 726911 FLAT WASHER - 1 1/2" 2
22 750494 LUBE HOSE - 12" "NOT PICTURED" 1
23 750495 FITTING - EL45 - 2MP - 2FPX "NOT PICTURED" 1
CHASSIS & BOOM ASSEMBLY
