71
RAYCO
®
RG 1635A STUMP CUTTER
ITEM # PART# DESCRIPTION QTY. INCLUDED IN
1 REF. CUTTING BOOM 1
2 716102 ENGINE DRIVE SHEAVE 1
3 716205 SHEAVE BUSHING 1
4 716206 JACKSHAFT DRIVE SHEAVE 1
5 716302 DRIVEN SHEAVE BUSHING 1
6 714202 PILLOW BLOCK BEARING 1
7 722336 SQUARE HEAD BOLT - 3/8 - 16 X 3" 4
8 724301 HEX NUT - 3/8 - 16 4
9 722505 HEX BOLT - 1/2 - 13 X 1 3/4 4
10 724501 HEX NUT - 1/2 - 13 4
11 726501 FLAT WASHER - 1/2" 4
12 726502 LOCK WASHER - 1/2" 4
13 4203 JACKSHAFT 1
14 716106 V-BELT 1
15 2581-01 KEY 1
16 4202 CUTTER WHEEL SHAFT 1
17 2583-12 KEY - 3/8" x 3 3/4" 1
18 3133 CUTTER WHEEL HUB 1
19 3732 CUTTER WHEEL 1
20 714302 PILLOW BLOCK BEARING 2
21 716714 DRIVE SPROCKET 1
22 716207 DRIVE SPROCKET BUSHING 1
23 716715 DRIVEN SPROCKET 1
24 716524 DRIVEN SPROCKET BUSHING 1
25 2-2581-03 KEY - 1/4" x 2" 1
26 2-2583-04 KEY - 3/8" x 2" 1
27 716607 POLY CHAIN BELT 1
28 722624 HEX HEAD BOLT - 9/16 - 18 X 2 1/2" 10
29 2-4900-04 FLAT WASHER - 9/16" 8
30 724602 HEX NUT - 9/16 - 18 20
31 722603 HEX HEAD BOLT - 9/16 - 12 X 1 1/2" 2
32 726602 LOCK WASHER - 9/16" 2
33 4900-15 CUTTER WHEEL WASHER 1
34 2-2279 CUTTER WHEEL WASHER 1
35 2-3144T TOOTH - STRAIGHT, TAPERED 2
36 2-3144C TOOTH - STRAIGHT, C-BORED 2
37 2-2933T TOOTH - RIGHT 14
38 2-2933C TOOTH - LEFT 14
39 718013 TOOTH POCKET BOLT 32
40 6875 JACKSHAFT COVER 1
41 722110 WHIZ BOLT - 1/4" x 3/4" 4
42 7503 SPACER 1
43 6874 JACKSHAFT DUST SHIELD 2
PARTS
CUTTING WHEEL DRIVE SYSTEM
