73
RAYCO
®
RG 1635A STUMP CUTTER
ITEM # PART# DESCRIPTION QTY. INCLUDED IN
1 7379 V-BELT GUARD 1
2 7331 V-BELT COVER 1
3 4611 BELT GUIDE 2
4 722330 BOLT, CARRIAGE - 3/8" - 16 x 3/4" 4
5 726301 WASHER, FLAT - 3/8" 6
6 726302 WASHER, LOCK - 3/8" 6
7 724301 NUT, HEX - 3/8" - 16 6
8 4523 POLYCHAIN GUARD 1
9 1793 POLYCHAIN GUARD COVER 1
10 722114 WHIZ BOLT - 3/8" - 16 x 3/4" 14
11 722303 BOLT, HEX - 3/8" - 16 x 1" 4
12 4440 END CAP 1
13 722509 BOLT, HEX - 1/2" - 13 x 3" 1
14 722510 BOLT, HEX - 1/2" -13 x 3 1/2" 1
15 724501 NUT, HEX - 1/2" - 13 2
16 4610 BELT GUIDE FRONT 2
17 726502 1/2" LOCK WASHER 1
PARTS
BELT GUARDS
