RAYCO
®
RG 1635A STUMP CUTTER
PARTS
ITEM # PART# DESCRIPTION QTY. INCLUDED IN
1 9728 ENGINE MOUNT - L.H. 1
2 9732 ENGINE MOUNT - R.H. 1
3 9747 CONTROL BAR 1
4 4163 BUSHING WELDMENT 1
5 724704 JAM NUT - 5/8" - 18 2
6 726501 FLAT WASHER - 1/2" 1
7 728003 COTTER PIN 1
8 9745 SAFETY CUTCH 1
9 738708 HANDLE GRIP 1
10 9750 ENGINE SLIDE HANDLE 1
11 9751 CLEVIS 4
12 9752 PUSH BAR 4
13 9183 MOUNTING YOLK TAB 1
14 9182 MOUNTING YOLK TAB 1
15 2581-04 KEY 1/4" SQUARE X 1" 1
16 2581-09 KEY 1/4" SQUARE X 1/2": 2
17 5456 SLIDE ROD 2
18 722508 HEX BOLT - 1/2" - 16 x 2 1/2" 8
19 726502 LOCK WASHER - 1/2" 8
20 724501 HEX NUT - 1/2" 4
21 722303 HEX BOLT - 3/8" - 16 x 1" 1
22 722306 HEX BOLT - 3/8" - 16 x 1 3/4" 2
23 724301 HEX NUT - 3/8" - 16 2
24 726302 LOCK WASHER - 3/8" 2
25 726906 FLAT WASHER - 1" 1
26 728019 CLEVIS PIN 4
27 728046 COTTER PIN 4
28 730076 GREASE ZERK - 1/4" x 90° 4
29 730065 GREASE ZERK - 1/4" x 45° 2
30 738707 HANDLE GRIP 1
31 750325 RETAINER RING 1
ENGINE SYSTEM SHEET 2 OF 2
