85
RAYCO
®
RG 1635A STUMP CUTTER
PARTS
ITEM # PART# DESCRIPTION QTY. INCLUDED IN
1 2723-01 SWING CYLINDER - LH 1
2 2723-02 SWING CYLINDER - RH 1
3 2215 CYLINDER SWING PIN 4
4 722201 HEX HEAD CAP SCREW - 5/16 - 18 X 2" 4
5 724201 HEX NUT - 5/16 - 18 4
6 726202 LOCK WASHER - 5/16" 4
7 730076 GREASE ZERK - 1/4 - 28 X 45° 4
HYDRAULIC SYSTEM SHEET 2 OF 4
