Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C100~RFL-C2000S
19
summer（Ambient temperature is higher than 30℃）29±0.5℃（RFL-C100~RFL-C1000）
summer（Ambient temperature is higher than 30℃）25±0.5℃ （RFL-C1500S/C2000S）
winter（Ambient humidity temperature is lower than 30℃）25±0.5℃
2) Coolant requirements:
The cooling water is pure water. It is recommended to use pure drinking water.
In order to prevent mould growing that may lead to pipe blockage, we recommend to
add alcohol about 10% of the total volume.
If the product is used in an environment that ambient temperature is between -10℃ and
0℃, we recommend to use 30% alcohol, and replace it every two months.
If the product is used in an environment that ambient temperature is below -10℃, please
to use dual-system chillers ( with heating function ) and ensure uninterrupted operation of the
cooling system.
3) Requirements for output cable cooling system:
Rate of liquid flow: 1.7-2.0 L/min;
Pressure of liquid flow: < 0.6 mPa at the inflow;
Type of liquid exchange junction: SMC MS-5H-6:
Type of tube: outer diameter ϕ6; inner diameter ϕ4;
Direction of cooling liquid: unidirectional; connect the tube with the water-pipe strictly
according to direction shown on the layer of the tube;
Type of liquid: de-ionized water, condensed water, pure water;
PH value of liquid: 5.5 - 9;
Filter is needed for the cooling system, and the size of the solid residual practicals
should be within 100um;
Maximum temperature of liquid: 45℃:
Minimum temperature of liquid: greater than the saturated dew-point 5℃;
