Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3300W~RFL-C15000W
10
Figure 2-a Front and rear view of the laser.
Figure 2-b Top and left view of the laser.
Figure 2 The dimensions of RFL-C6000X continuous wave fiber laser.
RFL-C6000X / C8000X two lasers share a set of cabinets.
(3) The dimensions of the RFL-C10000X / C12000X continuous wave fiber lasers
are shown in Figure 3 (taking RFL-C12000X as an example).
