rayence 1417WCE - Part Specifications

PART I. User & Installation Manual
38 1417WCE
2.4 Part Specifications
2.4.1 Detector
Parameter Spec. Unit
Sensor Type Amorphous Silicon with TFT (Single panel) -
Scintillator Type CsI:Tl -
Total Pixel Matrix
100 type: 3534 X 4302
140 type: 2500 X 3052
Pixels
Total Pixel Area
100 type: 353.4 X 430.2
140 type: 350.0 X 427.3
mm
Pixel Pitch
100 type: 100
140 type: 140
μm
Effective Pixel Matrix
100 type: 3450 X 4218
140 type: 2440 X 2992
Pixels
A/D Conversion 14 / 16 bits
Data Transfer
1Gbps Ethernet
802.11 n/ac Wireless LAN, up to 867Mbps
-
Energy range 40 ~ 150 kVp
Limiting Resolution
100 type: 5.00
140 type: 3.57
lp/mm
MTF (@1lp/mm)
100 – Typ. 62
140 – Typ. 57
%
DQE (@0lp/mm)
100 – Typ. 65
140 – Typ. 65
%
Dimension 384 X 460 X 15 mm
Weight ≤ 2.7 (incl. 1 battery) kg
Trigger mode
Manual Mode
Auto Trigger Mode (Auto Exposure Detection)
-
Power consumption 6 W
Wireless specifications
Standard
802.11 n/ac compliance
Without DFS (5.25GHz to 5.35GHz
and 5.47 to 5.725) Band
Peak Rate 1300Mbs
Frequency 2.4GHz / 5GHz
Bandwidth 20MHz / 40MHz / 80MHz
MIMO 3 X 3
 Limiting spatial resolution of 1417WCE is determined by its pixel pitch, 100/140 microns. In
theory, the detector cannot show higher resolution performance than 5.00/3.57 lp/mm.
 Maximum wireless signal rate derived from IEEE standard specifications. Actual data
throughput will vary. Network conditions and environmental factors, including volume of
network traffic, building materials and construction, and network overhead, lower actual
data throughput rate.
