rayence 1417WCE - Firmware, FPGA, and Firewall Configuration

PART II. Service Manual
98 1417WCE
2.3 Firmware, FPGA Update
1. Turn on the detector and connect to the PC. (IP address: 2.2.2.100)
• Connect as wired mode with the link cable (IP address: 2.2.2.101) or
wireless mode (IP address: 2.2.2.100)
2. After the detector is turned on, open “FPD_Manager.exe".
3. Check “ADI Wireless Model” check box.
4. Type detector's current IP address at "Detector IP Address" from "Current Setting" as
below.
 Detector's Ethernet Controller is operated with the second IP address,
192.168.124.80.
