PART I. User & Installation Manual
1417WCE 39
Recommended Maximum operable distance: 10m (From the Access Point)
Wireless Module and Wireless Antenna
• Wireless antennas: The module adopts the latest 802.11n Dual-Band technology
(2.4Ghz and 5Ghz). The transmitter of the module is powered by host equipment
(Detector). The antennas are 2 printed-dipole antennas.
• Wireless module: 1417WCE in the RF module does not use DFS band.
2.4.2 Battery [Model name: RB37BLA]
Parameter Spec. Unit
Size 205.9 X 88 X 6.4 mm
Weight 0.2 kg
Input 13.2 VDC
Output 11.55 VDC
Cycle life Max. 500 cycles
Operation temp. range 0~45
℃
Charging time Typ. 3 (Using the battery charger) hours
Capacity Typ. 3920 mAh
Operating time Typ. 8 hours
2.4.3 Battery charger [Model name: RMC002A]
Parameter Spec. Unit
Dimension 252 X 128 X 17.2 mm
Weight 0.25 kg
Input 19 VDC
Output 13.2 VDC
Pre charge Current 0.23 ± 25% A
Rapid Charging Current 2.3 ± 0.3 A
Charging Termination
Current
0.23 (+ 25%, - 65%) A
Recharge Vbatt Vterm - [ 0.15 ± 30%] V
Max Charging Time ≤ 180 min
Effiency ≥ 85% at 2.1A -
2.4.4 Battery charger Adaptor [Model name: ALM65US19]
Parameter Spec. Unit
Dimension 125.5 X 55.5 X 33.5 mm
Weight 0.3 kg
Input 80-264VAC, 47~63Hz, Typ. 1.2/0.6A (115/230VAC) -
