PART I. User & Installation Manual
40 1417WCE
Parameter Spec. Unit
Output 19VDC, 3.40A -
2.4.5 Power Supply (Optional) [Model name: RP003A]
Parameter Spec. Unit
Dimension 188 X 92 X 41.5 mm
Weight 0.5 kg
Rated power supply (Input) 100-240VAC (50/60Hz) -
Rated power supply (Output) Typ. 24VDC (Max 1.7A) -
2.4.6 AGI Box (Optional)
Parameter Spec. Unit
Dimension 92.5 X 119 X 33.5 mm
Weight 0.3 kg
2.4.7 Cable
Parameter Length Unit
Link cable (Shielded) 7 m
LAN cable (Shielded) 10 m
Power cord (3-Wire No Shielding) 1.8 m
USB cable (A to B type) 1.8 m
Trigger cable (Rayence I/F Cable) 10 m
P-interface cable (Rayence I/F Cable) 8 m
