Raymarine a9 Series - Electrical Connections; Distribution Panel Connection Wiring; Battery Connection Without RF Ground; Battery Connection With RF Ground

Distributionpanelconnection
Itisrecommendedthatyourproductiswiredthrough
yourvessel’sdistributionpanelviaathermalbreaker
orfuse.
D13017-1
2 31
4 5
6 7
1.Vesselpowersupplypositive(+)
2.In-linefuse.(Ifyourproductspowercabledoesnot
haveabuiltinfusethenanin-linefuseshouldbe
tted.)
3.Productpowercable
4.Vesselpowersupplynegative(-)
5.*Drainwire
6.Vesseldistributionpanel
7.*VesselRFgroundpointconnection
Note:*Onlyapplicabletoproductsthatincludea
drainwireontheproduct’spowercable.
BatteryconnectionwithRFground
Ifyourvesseldoesnothaveadistributionpanelthen
yourproductmaybewireddirectlytothebatterywith
thedrainwireconnectedtothevessel’sRFground
point.
D13018-1
2 4 51 3
6 7
1.Vesselpowersupplypositive(+)
2.Vesselpowersupplynegative(-)
3.In-linefuse(Ifyourproductspowercabledoesnot
haveabuiltinfusethenanin-linefuseshouldbe
tted.)
4.*Drainwire
5.Productpowercable
6.Vesselbattery
7.*VesselRFgroundpointconnection
Note:*Onlyapplicabletoproductsthatincludea
drainwireontheproduct’spowercable.
BatteryconnectionwithnoRFground
Ifyourvesseldoesnothaveadistributionpanelor
anRFgroundpointthenyourproductmaybewired
directlytothebatterywiththedrainwirealsoconnected
tothebattery’snegativeterminal.
D13019-1
2 4 51 3
6
1.Vesselpowersupplypositive(+)
2.Vesselpowersupplynegative(-)
3.In-linefuse(Ifyourproductspowercabledoesnot
haveabuiltinfusethenanin-linefuseshouldbe
tted.)
4.*Drainwireconnectedtovesselnegativepower
supply.
5.Productpowercable
6.Vesselbattery
Note:*Onlyapplicabletoproductsthatincludea
drainwireontheproduct’spowercable.
GA150connection
a9xanda12xMFDsincludeaninternalGNSS(GPS/
GLONASS)receiver.TheGA150antennacanbeused
toimprovetheGNSS(GPS/GLONASS)receiver’s
reception.
D13069-1
21
1.GA150antenna
2.a9xora12xvariantMFD
Forinstallationdetailsforyourexternalantenna,refer
tothedocumentationthataccompaniedtheantenna.
Note:
•TheBeidouGNSSissupportedbutnotcurrently
available.
•AGA150mustbeconnectedinordertoreceive
theBeidousystemwhenitbecomesavailable.
•Asoftwareupdatewillberequiredtoaddsupport
forBeidouoncethesystemisavailable.Please
checkwithyourRaymarinedealerforfurther
details.
Antennacablelength
TheGA150issuppliedwithatted10m(33ft.)cable.
Thelengthoftheantennacablecanbeextendedif
required.
Theantennacablelengthcanbeextendedbyupto
10m(33ft.)givingatotalmaximumcablelengthof
20m(66ft.)
50ohmcoaxialcableandreliableconnectors(offering
protectionagainstwateringress)mustbeusedwhen
extendingtheantennacable.
12
a9x/a12x
