Raymarine C120W - Default Chapter; Table of Contents

Contents
Chapter1ImportantInformation.............................7
TFTLCDDisplays..........................................................8
Wateringress.................................................................8
Disclaimers....................................................................8
CompactFlashcards.......................................................9
EMCinstallationguidelines.............................................9
Suppressionferrites........................................................10
Connectionstootherequipment......................................10
Declarationofconformity.................................................10
Productdisposal.............................................................10
Warrantyregistration.......................................................10
IMOandSOLAS.............................................................11
Technicalaccuracy.........................................................11
Chapter2Planningtheinstallation........................13
2.1Handbookinformation...............................................14
2.2Installationchecklist..................................................14
2.3C-Seriessystems......................................................15
2.4Packcontents...........................................................17
2.5T ools........................................................................19
Chapter3Cablesandconnections.........................21
3.1Generalcablingguidance..........................................22
3.2Connectionsoverview...............................................23
3.3Powerconnection.....................................................23
3.4SeaT alk
hs
network.....................................................26
3.5NMEA0183connection.............................................32
3.6SeaT alkconnection...................................................33
3.7Alarmconnection......................................................34
3.8GPSconnection........................................................35
3.9AISconnection..........................................................36
3.10Fastheadingconnection...........................................36
3.11SeaTalk
ng
connections.............................................37
3.12NMEA2000connection...........................................38
3.13Videoconnection.....................................................39
Chapter4Locationandmounting..........................41
4.1Selectingalocation...................................................42
4.2Flushmounting.........................................................45
4.3Bracket(trunnion)mounting.......................................46
4.4Frontbezel...............................................................48
Chapter5Systemchecks........................................51
5.1Initialpowerontest...................................................52
5.2GPScheck...............................................................53
5.3Radarcheck.............................................................54
5.4Sonarcheck.............................................................56
5.5Languageselection...................................................57
5
