Raymarine G-Series Installation Instructions

2
Handbook information
This installation guide contains information required to successfully
install and set up your wireless base station.
It is part of a series of documents associated with the G-Series
system. All documents can be downloaded from:
www.raymarine.com/handbooks
.
G-Series system documentation
Additional documents
You may also refer to separate instructions provided with the asso-
ciated ancillary equipment.
Errata
The documents supplied with the G-Series system contain a small
number of known errors:
87070-1 G-Series system installation guide
Page 20. System shown has one keyboard base station serving 2
keyboards, where 2 base stations are actually required. Each
keyboard requires a dedicated base station.
Page 41 & 42. Connection shows keyboard connected via ST70
instrument. Keyboards must be connected to a dedicated T-piece.
Page 65. Repeat base stations. These are not available for the wire-
less keyboard.
Installation sequence
Installation of the wireless keyboard system requires a structured
and planned approach. Use the following sequence of tasks:
Title Part number
G-Series system installation & commissioning
instructions
87070
G-Series command center keyboard installation
instructions
87084
G-Series command center keyboard wireless upgrade
kit installation instructions
87085
G- Series system operating guide 86126
G-Series system user reference guide 81276
PLANNING
1 Check pack contents
2 Plan system layout
3 Charge keyboard
4 Site Survey
We strongly recommend that you produce a complete schematic diagram for
your G-Series installation. Refer to the G-Series system installation and commis-
sioning instructions for templates and further information.
MOUNTING & CONNECTION
5 Mount base station in selected location.
6 Make all connections into equipment.
