Installation Templates T-1

GPS Antenna Mounting Template

Note: Access to the underside of the mounting surface must be available

to allow for secure fixing.

Cable Exit Channel

18mm

(0.7in)

6mm (0.25") dia.

for cable only

19mm (0.75") dia.

for NMEA plug

6mm (0.25") dia.

2 positions

18mm

(0.7in)

36mm (1.4in)

D4194-1
