Chapter 3: Operation 3-13
At the end is a section about using the ST60/80 Navigator Keypad to
select, edit and name your waypoints.
Placing a Waypoint
➤ To access the Place Waypoint soft keys, press MARK; the Place
Waypoint soft keys are displayed as shown in Figure 3-17:
Figure 3-17: Waypoint Soft Keys
➤ To place a waypoint at the cursor (plotter screen) or the vessel’s current
position:
1. Press either the PLACE WPT AT CURSOR or the PLACE WPT AT VESSEL
soft key. The waypoint is added to the Waypoint List and tagged using
the next available number.
If you place a waypoint at the cursor, the Waypoint soft keys shown
in Figure 3-23 are shown. Press CLEAR to remove these softkeys.
2. Press CLEAR to remove the Place Waypoint soft keys.
➤ To place a waypoint as a latitude/longitude position using the Waypoint
List:
1. Press MARK, followed by the WAYPOINT LIST soft key; the Waypoint
List and associated soft keys are displayed as shown in Figure 3-18:
Figure 3-18: Waypoint List and Soft Keys
The list details all waypoints in alpha-numerical order. The selected
waypoint is indicated by the highlight bar; its position in Lat/Long,
PLACE WPT
AT CURSOR
PLACE WPT
AT VESSEL
WAYPOINT
LIST
D4905-1
GOTO
WAYPOINT
EDIT
WAYPOINT
MAKE NEW
WAYPOINT
WAYPOINT
TRANSFER
SYMBOL NAME
WPT 001
WPT 002
WPT 003
WPT 004
N 50°50^000
W 001°06^000
POSITION
BRG 348°m
RNG 1.00nm
TEMP 20°C
DATE 23/11/01
DEPTH 12.3m
TIME 08:45:12
WAYPOINT LIST
D4906-2
