92
SPECIFICATIONS
Temperature Range - 30 to 900°C (- 25 to 1600°F)
Display Resolution 0.1°C (0.2°F)
Accuracy ± 1% of reading or ± 1°C (± 2°F),
(Infrared) whichever is greater at 25°C ± 5°C (77°F ± 9°F)
± 2°C (± 4°F) for targets below 0°C (32°F)
Ambient derating < 0.05K/K or 0.05 %/K, whichever is greater at
< 20°C (68°F) or > 30°C (86°F)
Accuracy ± 2K or ± 0.75 %, whichever is greater
(Thermocouple K/J)
Accuracy ± 0.6K
(Thermistor)
Repeatability ±0.5% of reading or ±1°C (2°F), whichever is greater
(Infrared) ± 2°C (± 4°F) for targets below 0°C (32°F)
Response Time (95%) 250 msec
Spectral Range 8 to 14 µm
Optical Resolution 60 : 1
Ambient Operating Range 0 to 50°C (32 to 122°F) Laser max 45°C (113°F)
Storage Temperature - 20 to 50°C (- 25 to 122°F)
without batteries
Analog output 1 mV/°C(°F)
Power 2 x 1.5 V Alkaline Type AA
Power supply 7.5 V
>
200 mA (Using the power supply the display
(external) automatically switches on)
Dimensions 200 x 170 x 50 mm (7.9 x 6.7 x 2 inches)
Tripod Mount 1/4-20 UNC
FACTORY DEFAULTS
Default Range
Emissivity/Gain 0.95 0.10 to 1.50 in steps of 0.01
Emissivity Table Free 30 materials
Mode normal
Hi Alarm 50°C (100°F) -30 to 900°C (-25 to 1600°F)
Lo Alarm 0°C (32°F) -30 to 900°C (-25 to 1600°F)
Offset Adjust 0°C (0°F) -10 to 10°C (-18 to 18°F)
Graphic Display Auto Range Auto Range / Man Range
- Cycle Time 0.5 sec 0.1 sec to 300 sec
Printer Mode Data Recording 3 modes,
selectable via software
Printer output ASCII
8 bits
1 Stop bit
No Parity
Baud Rate 9600 bd
Data logger 100,
pre-set with emissivity 0.95
Lo-Al: 0°C
Hi-Al: 50°C
adjustable only via Software (Accessory).
