Controller Addressing
Use DIP switches 1, 2, 3, and 4 to select the controller address. The address is binary coded and the
switch settings for all fifteen possible addresses are given below.
Controller Addressing
Switch 1
Switch 2
Switch 3
Switch 4
Address
Off
Off
Off
Off
Clear Memory
On
Off
Off
Off
1
Off
On
Off
Off
2
On
On
Off
Off
3
Off
Off
On
Off
4
On
Off
On
Off
5
Off
On
On
Off
6
On
On
On
Off
7
Off
Off
Off
On
8
On
Off
Off
On
9
Off
On
Off
On
10
On
On
Off
On
11
Off
Off
On
On
12
On
Off
On
On
13
Off
On
On
On
14
On
On
On
On
15
