Learning A Key Sequence
1. Place the RCU810 remote control unit and the other
remote control unit so that they face each other. They
should not be any more than 2 inches apart.
2. Press and hold the CODE SEARCH key until the remote
window displays CODE SET.
3. Step through the programming menu using the
UP (▲) key or DOWN (▼) key for IR LEARN,
then press the SELECT key.
4. Choose the desired device key then press the SELECT
key to continue on to the next step.
The remote will display LEARNING message for at
least 5 seconds to allow you to capture the IR data.
5. Press a valid key to be learned on the RCU810 remote
control in which you will store a new function.
The L
1, L2, L3 or other function keys may be used in this
programming mode. When using the other function keys
it is important to have the other remote in the same
device mode as the RCU810.
6. Press and hold the key on the other remote control,
which has the function you want to store. Hold the key
for at least 3 seconds or until a message displays in
the window.
7. Repeat steps 5 and 6 to store more functions.
8. When the selected functions are stored press the
CLEAR key to exit the IR LEARN programming
mode. The LCD display window will show a message
displaying EXIT SETUP and return to original operation
mode.
NOTES:
• Every time a code is successfully learned, the display
window will show SUCCESS.
• Press the CLEAR key at any time to exit the programming
mode. An EXIT SETUP message will appear confirming that
no new codes have been entered.
• If a key, which cannot learn another function, is pressed, the
display window will display an INVALID message.
• The learning capacity is approximately 16 to 25 keys,
depending on the function being learned.
The Learning feature is used as a supplement to the standard preprogrammed library. The
standard code library provides most of the functions needed, but you can add a small
number of additional functions of your choice.
RCU810
RCU810
14
OR
Any Other Function Key
