RCA RDR9000 User Manual

Service Manual 6. UHF1 (400-470 MHz) Information
120
No.
Ref. No.
Print No.
Part No.
Description
874
Q5003
B4D
ETCS03050000
Compound transistor
875
Q5005
B4D
ETCS03050000
Compound transistor
876
Q5006
B4J
ETCS03050000
Compound transistor
877
Q5007
B3D
ETCS03050000
Compound transistor
878
Q5008
B2J
ETCS03050000
Compound transistor
879
Q5009
B6D
ETCS03050000
Compound transistor
880
Q5010
B3D
ETCS03050000
Compound transistor
881
Q5019
B5D
ETCS03050000
Compound transistor
882
D5010
T4B
EDES14010000
ESD protection diode
883
D5024
T4B
EDES14010000
ESD protection diode
884
D5025
T2B
EDES14010000
ESD protection diode
885
D5026
T2B
EDES14010000
ESD protection diode
886
U2004
T2I
ESM032000000
Memory
887
D8004
T12A
EDSS11010000
Switching diode
888
D8005
T13B
EDSS11010000
Switching diode
889
U4006
T1C
ESG020000001
GPS module
890
X2000
T3K
EYAS32771001
Crystal
891
BT2000
B1I
EBE000001000
Button cell
892
Q2001
B2H
ETNS07010000
NPN transistor
893
Q1011
T5C
ETPS07010000
PNP transistor
894
Q1013
T4C
ETPS07010000
PNP transistor
895
D3000
B3F
EDES13010000
ESD protection diode
896
D3001
B4F
EDES13010000
ESD protection diode
897
D5002
T4A
EDES13010000
ESD protection diode
898
D5003
T2A
EDES13010000
ESD protection diode
899
D5004
T3A
EDES13010000
ESD protection diode
900
D5005
T3B
EDES13010000
ESD protection diode
901
D5006
T5B
EDES13010000
ESD protection diode
902
D5007
T3B
EDES13010000
ESD protection diode
903
D5011
B3B
EDES13010000
ESD protection diode
904
D5012
T4A
EDES13010000
ESD protection diode
905
D5016
T5J
EDES13010000
ESD protection diode
906
D5017
B6K
EDES13010000
ESD protection diode
907
D5018
B7K
EDES13010000
ESD protection diode
908
D1002
T5F
EDES13010001
ESD protection diode
909
D2002
T3K
EDES13010001
ESD protection diode
910
D5008
T3B
EDES13010001
ESD protection diode
911
D5014
B7K
EDES13010001
ESD protection diode
