Service Manual 6. UHF1 (400-470 MHz) Information
121
No.
Ref. No.
Print No.
Part No.
Description
912
D5020
T6J
EDES13010001
ESD protection diode
913
U2005
T5I
SMESM003000001
Memory
914
U8011
T13G
ESE010000001
Operational amplifier
915
U1004
T12G
ESH010000002
Power management IC
916
U1005
T12G
ESH010000002
Power management IC
917
U1008
T4F
ESH010000000
Power management IC
918
U3001
B5G
ESE002000001
Operational amplifier
919
U3004
B4G
ESE002000001
Operational amplifier
920
U1007
T5C
ESE010000000
Operational amplifier
921
U3002
T2G
ESE010000000
Operational amplifier
922
U2007
T5K
ESP014000000
Switch IC
923
U3005
B4I
ESP014000001
Three-way analog switch IC
924
U2001
T4K
ESP025000000
Two-way USB analog switch IC
925
U2000
T3I
ESN002000005
Baseband processor IC
926
Q6003
B15H
ETNS04010000
NPN transistor
927
Q6004
B15H
ETNS04010000
NPN transistor
928
Q6013
T12J
ETNS04010000
NPN transistor
929
Q6014
T12K
ETNS04010000
NPN transistor
930
Q7006
T8J
ETNS04010000
NPN transistor
931
D5019
B4K
EDES06010002
ESD protection diode
932
D2010
B5K
EDES06010003
ESD protection diode
933
D5001
T1B
ESJ025000000
USB protection IC
934
D5013
T6K
ESJ025000000
USB protection IC
935
Q1004
T7C
ETNS04040000
NPN transistor
936
D1005
T4C
EDXS03030000
Schottky barrier diode
937
D2000
B2I
EDXS03030000
Schottky barrier diode
938
D2003
B2I
EDXS03030000
Schottky barrier diode
939
D2004
B2I
EDXS03030000
Schottky barrier diode
940
D5015
B6B
EDXS03030000
Schottky barrier diode
941
Q8006
T9H
EFAS02010000
PA MOSFET
942
Q8005
T10H
EFAS02010001
PA MOSFET
943
U1003
T6H
ESH016000004
Power management IC
944
U1002
T5H
ESH016000003
Power management IC
945
U1009
T1J
ESH016000000
Power management IC
946
U1006
T6G
ESH016000002
Power management IC
947
U1010
T4F
ESH016000002
Power management IC
948
U1011
T2D
ESH016000002
Power management IC
949
U1012
T12H
ESH016000002
Power management IC
