RCA RDR9000 User Manual

Service Manual 7.UHF3 (350-400 MHz) Information
222
No.
Ref. No.
Print No.
Part No.
Description
850
Q5020
T13C
ETCS03020001
Compound transistor
851
Q5000
B2D
ETCS03050000
Compound transistor
852
Q5001
B4F
ETCS03050000
Compound transistor
853
Q5002
B6D
ETCS03050000
Compound transistor
854
Q5003
B4D
ETCS03050000
Compound transistor
855
Q5005
B4D
ETCS03050000
Compound transistor
856
Q5006
B4J
ETCS03050000
Compound transistor
857
Q5007
B3D
ETCS03050000
Compound transistor
858
Q5008
B2J
ETCS03050000
Compound transistor
859
Q5009
B6D
ETCS03050000
Compound transistor
860
Q5010
B3D
ETCS03050000
Compound transistor
861
Q5019
B5D
ETCS03050000
Compound transistor
862
D5010
T4B
EDES14010000
ESD protection diode
863
D5024
T4B
EDES14010000
ESD protection diode
864
D5025
T2B
EDES14010000
ESD protection diode
865
D5026
T2B
EDES14010000
ESD protection diode
866
U2004
T2I
ESM032000000
Memory
867
D8004
T12A
EDSS11010000
Switching diode
868
D8005
T13B
EDSS11010000
Switching diode
869
U4006
T1C
ESG020000001
GPS module
870
X2000
T3K
EYAS32771001
Crystal
871
BT2000
B1I
EBE000001000
Button cell
872
Q2001
B2H
ETNS07010000
NPN transistor
873
Q1011
T5C
ETPS07010000
PNP transistor
874
Q1013
T4C
ETPS07010000
PNP transistor
875
D3000
B3F
EDES13010000
ESD protection diode
876
D3001
B4F
EDES13010000
ESD protection diode
877
D5002
T4A
EDES13010000
ESD protection diode
878
D5003
T2A
EDES13010000
ESD protection diode
879
D5004
T3A
EDES13010000
ESD protection diode
880
D5005
T3B
EDES13010000
ESD protection diode
881
D5006
T5B
EDES13010000
ESD protection diode
882
D5007
T3B
EDES13010000
ESD protection diode
883
D5011
B3B
EDES13010000
ESD protection diode
884
D5012
T4A
EDES13010000
ESD protection diode
885
D5016
T5J
EDES13010000
ESD protection diode
886
D5017
B6K
EDES13010000
ESD protection diode
