Service Manual 7.UHF3 (350-400 MHz) Information
223
No.
Ref. No.
Print No.
Part No.
Description
887
D5018
B7K
EDES13010000
ESD protection diode
888
D1002
T5F
EDES13010001
ESD protection diode
889
D2002
T3K
EDES13010001
ESD protection diode
890
D5008
T3B
EDES13010001
ESD protection diode
891
D5014
B7K
EDES13010001
ESD protection diode
892
D5020
T6J
EDES13010001
ESD protection diode
893
U2005
T5I
SMESM003000001
Memory
894
U8011
T13G
ESE010000001
Operational amplifier
895
U1004
T12G
ESH010000002
Power management IC
896
U1005
T12G
ESH010000002
Power management IC
897
U1008
T4F
ESH010000000
Power management IC
898
U3001
B5G
ESE002000001
Operational amplifier
899
U3004
B4G
ESE002000001
Operational amplifier
900
U1007
T5C
ESE010000000
Operational amplifier
901
U3002
T2G
ESE010000000
Operational amplifier
902
U2007
T5K
ESP014000000
Switch IC
903
U3005
B4I
ESP014000001
Three-way analog switch IC
904
U2001
T4K
ESP025000000
Two-way USB analog switch IC
905
U2000
T3I
ESN002000005
Baseband processor IC
906
Q6003
B15H
ETNS04010000
NPN transistor
907
Q6004
B15H
ETNS04010000
NPN transistor
908
Q6013
T12J
ETNS04010000
NPN transistor
909
Q6014
T12K
ETNS04010000
NPN transistor
910
Q7006
T8J
ETNS04010000
NPN transistor
911
D5019
B4K
EDES06010002
ESD protection diode
912
D2010
B5K
EDES06010003
ESD protection diode
913
D5001
T1B
ESJ025000000
USB protection IC
914
D5013
T6K
ESJ025000000
USB protection IC
915
Q1004
T7C
ETNS04040000
NPN transistor
916
D1005
T4C
EDXS03030000
Schottky barrier diode
917
D2000
B2I
EDXS03030000
Schottky barrier diode
918
D2003
B2I
EDXS03030000
Schottky barrier diode
919
D2004
B2I
EDXS03030000
Schottky barrier diode
920
D5015
B6B
EDXS03030000
Schottky barrier diode
921
Q8006
T9H
EFAS02010000
PA MOSFET
922
Q8005
T10H
EFAS02010001
PA MOSFET
923
U1003
T6H
ESH016000004
Power management IC
