DESCRIPTION
ES 3080 is a 80 W mixer-amplier, with 2 mic-line audio inputs on removable connectors
(the rst input also has an XLR socket), an MP3 player with ‘Bluetooth’ and an aux input
for a music source (e.g. CD players, tuners, etc.).
The input 2 also has an RJ 45 port for quick connection of an RCF BM 3001 paging
microphone (through CAT5 cable).
The amplier output is available either for low impedance speakers (min. 4 Ω) or 100 – 70 V
constant voltage line (for speakers having 100 – 70 V transformers).
The input 1 has a signal detection circuit (‘VOX’) for automatic priority.
The inputs 1 and 2 can access the priority through an external command (connected to
either the removable connector or the RJ 45 port).
The MUSIC ON HOLD output directly sends the internal MP3 player signal to additional
ampliers, mixers, phone systems (‘music on hold’ function), etc. .
The PRE OUT output sends the signal (the same routed to the internal amplier) to
additional ampliers.
The 2 mic-line inputs have a high-pass lter (with a common on/off dip-switch) that are
useful to improve speech intelligibility.
The internal MP3 player and the AUX INPUT have tone controls (common for both).
Front panel LEDs indicate the device state (ON, PROT), priority circuit enabled (PRIOR) and
the signal level / peak (SIG/PK).
RCF S.P.A. THANKS YOU FOR PURCHASING THIS PRODUCT, WHICH HAS BEEN
DESIGNED TO GUARANTEE RELIABILITY AND HIGH PERFORMANCES.
FRONT PANEL
PLAY / PAUSE
MP3 PLAYER
AUX IN
STOP BT PAIR
ON/OFF
ES
80W AUDIO SOURCE
MIXER AMPLIFIER
5 4
1
3
123
2
6 7 89
