RCF EVOX 5 - Specifications; Acoustical Specifications; Amplifier;DSP Specifications; Subwoofer Physical Dimensions

11
ENGLISH
EVOX 5 EVOX 8
ACOUSTICAL
Frequency response 45 Hz ÷ 20 kHz 40 Hz ÷ 20 kHz
Maximum sound pressure level 125 dB 128 dB
Horizontal coverage angle 120° 120°
Vertical coverage angle 30° 30°
Subwoofer transducers 10” (2.0” voice coil) 12” (2.5” voice coil)
Satellite transducers 5 x 2” (1.0” voice coil) 8 x 2” (1.0” voice coil)
AMPLIFIER / DSP
Amplier power (low frequencies) 600 W (peak) 1000 W (peak)
Amplier power (high frequencies) 200 W (peak) 400 W (peak)
Input sensitivity (LINE) +4 dBu +4 dBu
Crossover frequency 220 Hz 220 Hz
Protections thermal drift, RMS thermal drift, RMS
Limiter software limiter software limiter
Cooling convective convective
Operating voltage
115 / 230 V (according to the model),
50-60 Hz
115 / 230 V (according to the model),
50-60 Hz
Inrush current
10,1 A
(According to EN 55013-1: 2009)
10,1 A
(According to EN 55013-1: 2009)
SUBWOOFER PHYSICAL
Height 490 mm (19.29”) 530 mm (20.87”)
Width 288 mm (11.34”) 346 mm (13.62”)
Depth 427 mm (16.81”) 460 mm (18.10”)
Net weight 19.2 kg (42.33 lbs) 23.8 kg (52.47 lbs)
Cabinet Baltic birch plywood Baltic birch plywood
SPECIFICATIONS
