RCF EVOX 8 User Manual

10
ENGLISH
EVOX 12
ACOUSTICAL
Frequency response 40 Hz ÷ 20 kHz
Maximum sound pressure level 130 dB
Horizontal coverage angle 90°
Vertical coverage angle 30°
Subwoofer transducers 15” (3.0” voice coil)
Satellite transducers 8 x 4” (1.0” voice coil)
AMPLIFIER / DSP
Amplier power (low frequencies) 1000 W (peak)
Amplier power (high frequencies) 400 W (peak)
Input sensitivity (LINE) +4 dBu
Crossover frequency 180 Hz
Protections thermal, RMS
Limiter software limiter
Cooling convective
Operating voltage 115 / 230 V, 50-60 Hz
Inrush current
10,1 A
(According to EN 55013-1: 2009)
SUBWOOFER PHYSICAL
Height 2220 mm (87.4”)
Width 410 mm (16.14”)
Depth 560 mm (22.05”)
Net weight 36.4 kg (80.24 lbs)
Cabinet Birch plywood
SPECIFICATIONS

RCF EVOX 8 Specifications

General

Max SPL	128 dB
Input Connectors	XLR, Jack
Vertical Coverage Angle	30°
Total Power	1400 W Peak
HF Power	400 W Peak
LF Power	1000 W Peak
Amplifier Class	Class D
Output Connectors	XLR
Protections	Thermal, RMS
Limiter	Soft Limiter
Controls	Volume, EQ
Cabinet Material	Baltic birch plywood
Hardware	Pole mount
Color	Black
Weight	23.8 kg
LF Driver	12", 2.5" voice coil
Input Sensitivity	+4 dBu
Standard Compliance	CE
Woofer	12"
Crossover Frequency	2.2 kHz
