RCF HDL 12-AS User Manual

SPECIFICATIONS
HDL 6-A HDL 12-AS
Frequency Response 65 Hz - 20 kHz 40 Hz - 120 kHz
Max Spl 131 dB 131 dB
Horizontal Coverage Angle 100° -
Vertical Coverage Angle 10° -
Compression Driver 1.0” neo, 1.7”v.c. -
Woofer 2 x 6.0” neo, 2.0”v.c. 12”, 3.0”v.c.
INPUTS
Input Connector XLR male Stereo XLR
Output Connector XLR female Stereo XLR
Input Sensitivity + 4 dBu - 2 dBu/+ 4 dBu
PROCESSOR
Crossover Frequency 900 Hz 80-110 Hz
Protections Thermal, RMS Thermal, RMS
Limiter Soft limiter Soft limiter
Controls HF correction Volume, EQ, phase, xover
AMPLIFIER
Total Power 1400 W Peak 1400 W Peak
High Frequencies 400 W Peak -
Low Frequencies 1000 W Peak -
Cooling convection convection
Connections Powercon in-out Powercon in-out
PHYSICAL SPECIFICATIONS
Height 237 mm (9.3”) 379 mm (14.9”)
Width 470 mm (18.7”) 470 mm (18.50”)
Depth 377 mm (15”) 508 mm (20”)
Weight 11.5 Kg (25.35 lbs) 24 Kg (52.9 lbs)
Cabinet Composite PP Baltic Birch Plywood
Hardware Integrated mechanics Array fittings, pole
Handles 2 rear 2 side

RCF HDL 12-AS Specifications

General

Brand	RCF
Model	HDL 12-AS
Category	Subwoofer
Language	English
