SPECIFICATIONS
IPS 700 IPS 1700 IPS 2700 IPS 3700
RATED
OUTPUT POWER
4 Ω - stereo
(per channel)
300 W 450 W 1100 W 1500 W
8 Ω - stereo
(per channel)
150 W 330 W 700 W 1200 W
8 Ω - bridged 600 W 900 W 2200 W 3000 W
Frequency response 20 Hz ÷ 20 kHz (+0 –1 dB, 1 W)
Total harmonic distortion < 0.5% (20 Hz ÷ 20 kHz)
Damping factor > 200 (8 Ω, 10 ÷ 400 Hz)
Slew rate > 10 V / µs
Signal / noise ratio > 100 dB
Crosstalk –75 dB (1 kHz)
Input sensitivity for
full rated power (8 Ω)
0.775 V / 1.4 V
Input impedance 20 kΩ (balanced), 10 kΩ (unbalanced)
Protections
DC, internal fault, input overload, RF interference,
unmatched load, output short-circuit, thermal drift,
power supply over-current
Cooling Internal heat sinks and forced ventilation (speed regulated fan)
Operating voltage 115 V / 230 V (according to the model), 50-60 Hz
Power consumption 350 W 350 W 700 W 800 W
Inrush current 8 A 11 A 15 A 22 A
Power cord input IEC 10 A IEC 10 A IEC 16 A IEC 16 A
Dimensions
(19” rack, 2 U)
width 482 mm 482 mm 482 mm 482 mm
height 88 mm 88 mm 88 mm 88 mm
depth 255 mm 255 mm 255 mm 324 mm
Net weight 10.1 kg 12.7 kg 14.5 kg 19.5 kg
