5. INSTALLATION
FLOOR CONFIGURATIONS
Several configurations are possibile with NX 985-A; they can be placed on the floor or on a stage as main PA or placed on a subwoofer in a single
or coupled configuration (reccomended subwoofer RCF SUB 8008-AS)� For system alignment refer to the documentation on www�rcf�it�
FLOOR OR STAGE
STANDING
SINGLE CONFIGURATION
ON A SUBWOOFER
COUPLED CONFIGURATION
ON A SUBWOOFER
SUSPENDED CONFIGURATION
NX 985-A can be hanged with cables or chains by using M10 threaded eyebolts (not included) screwed on the M10 suspension points located
on the top and bottom side of the speaker�
SUSPENDED CONFIGURATION
THROUGH THE USE OF CHAINS
