5 The pickup is asymmetric and can be fit in two positions
(A and B). A position brings the shackle towards the front. B
position allows an intermediate step using the same fixing
holes
6 Move the pickup bracket in the position suggested by RCF
Shape Designer
7 Fix the pickup bracket with the two pins on the bracket’s
lanyard to lock the pickup
8 Check that all the pins are secured and locked
