RCF TTL31-A User Manual

51
TTL33-A
ACOUSTICAL
Operating frequ. range 60 - 20.000 Hz
Max SPL 135 dB
Horizontal Coverage 100°
Vertical Coverage 15°, depending on configuration
Crossover points 400 Hz, 1.800 Hz
TRANSDUCERS
Low frequency 2 x 8”midbass neo, 64 mm voice coil
Mid frequency 1 x 8” midrange neo, 64 mm voice coil
High frequency 3 x 1” compression driver
AMPLIFIER
Total power supply switching 750 Watt
Low section D / 500 Watt
Mid section D / 500 Watt
High section D / 250 Watt
CONNECTIONS
Signal Input/Output XLR male/female
Power Input/Output Powercon male/female
CONFIGURATION CONTROLS
Array size control (2/3-4/6-7/9-10/16)
Distance control (Near - Mid - Long)
Full range / high pass
Volume Control
DSP PROCESSOR
• 32 bits, 96 KHz sampling, floating point
• 3 way equalisation, crossover filtering,
fast limiter, RMS limiter.
• array size configuration set-up
• distance correction set-up
• low filtering set-up
MECHANICAL
Size 760 x 300 x 450 mm
Weight 33 Kg
TTL55-A
ACOUSTICAL
Operating frequ. range 50 - 20.000 Hz
Max SPL 143 dB
Horizontal Coverage 90°
Vertical Coverage max 7°
Crossover points 20 Hz, 1.300 Hz
TRANSDUCERS
Low frequency 2 x 12”midbass neo, 100 mm voice coil
Mid frequency 1 x 10” midrange neo, 89 mm voice coil
High frequency 3 x 1.5” compression driver
AMPLIFIER
Total power supply switching 3500 Watt
Low section D / 2 x 1000 Watt
Mid section D / 1000 Watt
High section D / 500 Watt
CONNECTIONS
Signal Input/Output XLR Ethercon
Power Input/Output Powercon
CONFIGURATION CONTROLS
Array size control (????????????)
Distance control (?????????????)
???????????
???????????
DSP PROCESSOR
• 32 bits, 96 KHz sampling, floating point
• 3 way equalisation, crossover filtering,
fast limiter, RMS limiter.
• array size configuration set-up
• distance correction set-up
• low filtering set-up
MECHANICAL
Size 1020 x 380 x 550 mm
Weight 67 Kg
8.
TECHNICAL SPECIFICATIONS
