RCO R-COD 500 - Product Specifications

R-COD 500 & R-COD 500 IR SPECIFICATIONS
14
Specifications
AD/CD specification (t = +20°C) Min. Typ Max. Unit
Supply voltage DC 10 30 V
AC 8 24 V
Power consumption Idle 31 (IR) / 26 mA
Backlight on 21 mA
Relay on 24 mA
Max. total 50 71 (IR) / 66 mA
Temperature range at 24 V AC
and max. power consumption
-30 +70 °C
Current at 24 V DC Relay, single pole 1 A
Number of access codes 8 st.
Number of IR codes (only R-COD 500 IR) 5 st.
Reading distance of IR receiver (only R-COD 500 IR) 10 m
Dimensions (B x H x D) Surface mounting: 70 x 144 x 37 mm
Box for recessed mounting: 76 x 204 x 28 mm
Front frame for recessed mouting (b x h): 94 x 239 mm
Weight 0.6 kg
