RCS TBZ48 Installation Guide

Thermostat Menu Mode
The Thermostat has a menu of setup and information displays.
To change to the Menu Mode, press and hold the FAN button for 5 seconds.
The display will change to the Menu Mode and display the Setup screen.
Use the Up/Down arrow buttons to scroll through other menu items.
Thermostat Main Screen
Menu Mode Screen
Menu Mode options
• SETUP User preference settings
• SYSTEM Thermostat HVAC system settings
• ZWAVE Z-Wave network install or remove
• CLOCK Setting the thermostat time and day
• INFO Displays thermostat version and setup info
Press and hold the
FAN button for 5
seconds to go to
the Menu Mode
screen
Use the
UP/DOWN
buttons to select
the desired menu
item
Press “Select”
to go to the
selected menu
item screen
Press “Done” to go back to the
Thermostat Main Screen
72H 80C
7
Off
Auto
MODE
FAN
SETUP
Select
Done
MODE
FAN
Menu item display
DCN: 140-02121-06 Page 16
