SETUP Menu
User preference settings.
FAHRENHEIT OR CELSIUS. Select the temperature display mode.
BACKLIGHT TIMEOUT. Sets the time from last button press that the backlight will turn off.
Range:10-30 seconds. Note: long backlight timeouts will reduce battery life.
If the thermostat is powered from 24VAC, the backlight timeout can be set to “0” which will
keep the backlight on continuously.
SENSOR CALIBRATION Change the temperature calibration by +/- 7 degrees.
Use the Up/Dn arrow buttons to change to the desired display temperature.
SYSTEM Menu
SYSTEM TYPE. Select the system type, STANDARD or HEAT PUMP
FAN TYPE (Standard systems only).
Select fan type: GAS (typical default setting) or ELECTRIC
CHANGE OVER TYPE (Heat Pump systems only).
Select the Changeover type:
Changeover WITH COOL (typical default setting)
Changeover WITH HEAT
See Installation Guide for more information on System setup and the Advanced Systems
Menu
Z-WAVE Menu
This menu item allows the thermostat to be enrolled to the ADT Pulse
®
Network. Follow the
instructions shown in the Z-Wave® Operation section (page 19) to enroll the Thermostat
onto the ADT Pulse
®
system.
CLOCK Menu
Set the time and day of the week.
Press select to set the DAY. The current day of the week setting will be displayed.
Press the UP/DN arrows to change the day of the week desired.
Press select to set the TIME. The current time will be displayed.
Press the UP/DN arrows to change the time.
DCN: 140-02121-06 Page 17
