Real Flame ELEMENT 1200 - Page 37

37
TIMBER FRAME INSTALLATION
18mm Trim
1. Install Element 1200 onto base and connect flue, gas and power.
2. Fit 18mm trim frame.
3. Locate 4 sided flange kit.
4. Remove 18mm frame.
5. Clad wall to flange kit and finish.
6. Refit 18mm trim frame.
1
2
1
4
6
5
3
