MEDIA INSTALLATION (continued)
Coals only
• Lay coal media in a random arrangement along the entire length of the burner.
• Avoid smothering the burner channel. Apply coals either side of the flame channel.
• No more than 4 coals should cover the main flame channel.
• Ensure media is not heaped in areas, spread evenly along.
• Do not add extra media, or combine media types.
• Only the approved supplied media is to be used.
• Do not cover pilot area.
• Do not overfill with media above the pilot cover level.
• Ensure the pilot flame is not impinged by media and can cross light the main burner.
• Do not use any other media than as supplied and recommended by the manufacturer.
• Use of other media may result in explosive media which may cause injury or damage.
Typical setup
40
