MEDIA INSTALLATION (continued)
Pebbles
• Lay large pebble media in a random arrangement along the entire length of the burner.
• Avoid smothering the burner channel.
• Fill in voids with medium size pebbles.
• Fill in remaining voids with small pebbles.
• Pebbles should appear as a random mix and not be stacked more than 2 high in a few spots.
• Ensure media is not heaped in areas, spread evenly along.
• Do not add extra media, or combine media types.
• Only the approved supplied media is to be used.
• Refer to Real Flame for technical advice regarding media.
• Do not cover pilot area.
• Do not overfill with media above the pilot cover level.
• Ensure the pilot flame is not impinged by media and can cross light the main burner.
• Do not use any other media than as supplied and recommended by the manufacturer.
• Use of other media may result in explosive media which may cause injury or damage.
Typical setup
42
