Rebotec Arnold 150 - Page 15

REBOTEC / BA-Nr.: 02.09.200/2021-08-A01
- 15 -
EN
No.
Art. no.
Designation
-
02.09.200
User Manual for Arnold 150/125
-
02.10.141
Guide for Slings
-
02.11.152
Maintenance Instructions for Hoist
-
02.12.160
Reprocessing Instructions
1
425.19.71
Linear drive
2
425.19.72
Control unit
3
425.19.73
Rechargeable battery unit
4
425.19.75
Manual switch
5a
425.19.74
Charging cable, EU plug
-
425.19.76
Charging cable, US plug
-
425.19.78
Charging cable, KR plug
5b
425.19.77
Fuse set for charging cable
6
443.10.80
Front castor (Ø 75 mm)
7
443.10.85
Rear castor (Ø100 mm)
8
420.00.15
Rubber cap for pedal
9
420.00.12
Pedal
10
420.28.83
Angle joint rod (L=280 mm) (Arnold 150)
10
420.25.83
Angle joint rod (L=250 mm) (Arnold 125), RH
10
420.22.83
Angle joint rod (L=230 mm) (Arnold 125), LH
11
420.99.22
Handles for D22x90 mm column
-
420.95.22
Handles for D22x120 mm column
12
420.00.43
D25x155 bolt
13
420.00.42
Four-point sling hanger, standard
14
420.58.97
SL24/1.5 key ring
15
420.04.30
Brass washer for round steel bolt
16
420.00.13
Screwing set for sling hanger M10
-
420.10.42
Four-point sling hanger, wide
-
420.00.14
Screwing set for centre of rotation
-
420.06.00
Hoist scales for A150 with sling mounting bracket (*)
*Installation height of the sling mounting bracket + hoist scales = 204mm from CSP (See 21).
Use only REBOTEC spare parts and accessories to ensure the proper and safe functioning of the
device.
