Rebotec Arnold 150 - Page 17

REBOTEC / BA-Nr.: 02.09.200/2021-08-A01
- 17 -
EN
Arnold 150
No.
Designation
Dimensions
in mm
1
Highest point
2
Highest point at highest reach
3
Lowest point
a
Highest reach at a height of 600 mm (reference height)
630
b
Highest reach from the base frame
645
c
Reach from the base frame when expanding the leg supports to 700 mm
350
d1
Front castor diameter
75
d2
Rear castor diameter
100
e
Total height (without arm)
1265
f
Length of the base frame
1170
g
Distance of the push handles
480
h
Turning diameter
1315
k
Maximum height of the CSP
1975
l
Minimum height of the CSP
775
m
Lifting range
1200
n
Height of the base frame
120
o
Clearance of the base frame
70
p
Maximum inner width
900
q
Inner width at highest reach
828
r
Minimum inner width
525
x
Minimum distance from the wall to the CSP at its greatest height (spread apart)
545
y
Minimum distance from the wall to the CSP at its lowest height (spread apart)
320
z
Minimum distance from the wall to the CSP at its highest reach (spread apart)
190
Arnold 125
No.
Designation
Dimensions
in mm
1
Highest point
2
Highest point at highest reach
3
Lowest point
a
Highest reach at a height of 600 mm (reference height)
335
b
Highest reach from the base frame
350
c
Reach from the base frame when expanding the leg supports to 700 mm
450
d1
Front castor diameter
75
d2
Rear castor diameter
100
e
Total height (without arm)
1265
f
Length of the base frame
970
g
Distance of the push handles
480
h
Turning diameter
1150
k
Maximum height of the CSP
1790
l
Minimum height of the CSP
830
m
Lifting range
960
n
Height of the base frame
120
o
Clearance of the base frame
70
p
Maximum inner width
735
q
Inner width at highest reach
660
r
Minimum inner width
450
x
Minimum distance from the wall to the CSP at its greatest height (spread apart)
470
y
Minimum distance from the wall to the CSP at its lowest height (spread apart)
350
z
Minimum distance from the wall to the CSP at its highest reach (spread apart)
220
Dimensions vary depending on the equipment. There might be minor deviations due to production
tolerances. Subject to change without notice.
