Owners/Installation Manual – Controller v2 | Reclaim Energy
RECLAIMENERGY.COM.AU
17
SECTION
2
Any previously configured Wi-Fi network will
be erased.
• The first line will alternate between the Wi-Fi
network name and the prompt ‘ENTER PASSWORD’.
• The symbol in the top right corner denotes the
current type of input; press the BOOST button to
change the input type as per Table 1.
• When the connection is successful, the network
information is displayed as in Figure 3-8. Otherwise,
the message in Figure 3-6 is displayed.
• After selecting the network, enter the Wi-Fi
password; press the ▲ / ▼ keys to change the
character, press the to move the cursor and
press ENTER to confirm.
Figure 2-32: Reset Wi-Fi
RESET WIFIRESET WIFI
YESYES
Figure 2-34: Controller name
NAMENAME
RECLAIMV2RECLAIMV2
Figure 2-35: Firmware version
FIRMWARE VERFIRMWARE VER
V1.00V1.00
Figure 2-36: Wi-Fi MAC address
MAC ADDRESSMAC ADDRESS
0123456789AB0123456789AB
Figure 2-33: Wi-Fi settings reset
WIFI SETTINGSWIFI SETTINGS
RESET OKRESET OK
Figure 2-30: Wi-Fi networks’ information
MyNetwork123MyNetwork123
-30dBm WPA/2-30dBm WPA/2
Figure 2-31: Enter Wi-Fi password
ENTER PASSWORD#ENTER PASSWORD#
abc123_abc123_
2.4 ABOUT
This menu allows you to view various information about
the controller per the below:
• Name
• Firmware Version
• Wi-Fi MAC Address
• App Code
• Ambient Temperature
• Certificate ID.
2.3.3 RESET WIFI SETTINGS
To reset the Wi-Fi network settings, select Yes and
press the ENTER key.
2.4.1 CONTROLLER NAME
The name can be setup in the App e.g., ‘John’s House’.
2.4.2 FIRMWARE VERSION
The firmware version is displayed on this screen.
2.4.3 WIFI MAC ADDRESS
The Wi-Fi MAC address is displayed on this screen.
