Reclaim Energy | Owners/Installation Manual – Controller v2
16
SECTION
2
• Press the Enter key to view the Wi-Fi signal strength
and IP address.
• The controller will start to search for nearby
Wi-Fi networks.
• The lists of Wi-Fi networks found is listed in order
of signal strength (strongest to weakest) and the
network security type is also displayed; press the
▲ / ▼ keys to select the network.
• If not currently connected to a Wi-Fi network, the
above information will be blank.
• From the Wi-Fi information screen, press the Enter
key to access the next menu which allows to setup
the Wi-Fi network manually.
Figure 2-24: Wi-Fi network info
WIFI NETWORKWIFI NETWORK
MyNetwork123MyNetwork123
Figure 2-28: Search for Wi-Fi networks
SEARCH WIFISEARCH WIFI
YESYES
Figure 2-29: Searching for Wi-Fi networks
SEARCHING FORSEARCHING FOR
WIFI NETWORKWIFI NETWORK
Figure 2-27: Setup Wi-Fi manually
SEARCH WIFISEARCH WIFI
NONO
Figure 2-25: Wi-Fi network signal strength
WIFI SIGNALWIFI SIGNAL
-35dBm (100%)-35dBm (100%)
Figure 2-26: IP address info
IP ADDRESSIP ADDRESS
192.168.0.100192.168.0.100
2.3.1 WIFI NETWORK INFORMATION
If ‘ON’ is selected, the Wi-Fi network information is
displayed if currently connected.
2.3.2 MANUALLY SETUP WIFI
To setup the Wi-Fi network using the LCD/keypad,
select Yes and press the ENTER key.
SETUP CONT.
• Press the ▲ / ▼ keys to choose to select ON or OFF.
• If ‘OFF’ is selected, the controller operates in
OFFLINE mode.
The input cursor will blink on the year; press the ▲ / ▼
keys to change the value and press ENTER to confirm.
The cursor will then move to the month and so on to the
date, hour, and minute.
Figure 2-23: Wi-Fi on/off
WIFIWIFI
ONON
2.3 WiFi
This menu allows to turning the Wi-Fi on/off as well as
to view and/or change the network settings.
Figure 2-21: Manually set date
SET DATESET DATE
2021/08/132021/08/13
Figure 2-22: Manually set time
SET TIMESET TIME
12:01 PM12:01 PM
2.2.2 MANUALLY SET DATE/TIME
If ‘No’ is selected for Auto Set Clock, the date/time can
be set manually.
