Owners/Installation Manual – Controller v2 | Reclaim Energy
RECLAIMENERGY.COM.AU
27
SECTION
4
4 STATUS DISPLAY
The controller displays various status information when
the menu is not active. This includes:
• Date/Time & location
• Heat Pump Status
• Tank Temperature
• Operation Mode
• Wi-Fi Connection Status
• Fault(s)
4.1 DATE/TIME & LOCATION
The current date and time are shown on this screen.
The location is also shown when the clock settings are
set to AUTO.
4.2 HEAT PUMP STATUS &
TANK TEMPERATURE
The heat pump status and the tank temperature are
shown on this screen. The different possible scenarios
are displayed as follows:
• If the heat pump is on, the heat pump status and
temperature T-OFF are displayed as per below.
• If the heat pump is off, the heat pump status and
temperature T-ON are displayed as per below.
Figure 4-1: Location, date & time
01/01/202201/01/2022
12.00 AM12.00 AM
Figure 4-2: Heat pump on
HEAT PUMP:ONHEAT PUMP:ON
TANK:36TANK:36
¯ ¯
TOF:59TOF:59
¯¯
Figure 4-3: Heat pump off
HEAT PUMP:OFFHEAT PUMP:OFF
TANK:52TANK:52
¯ ¯
TOF:37TOF:37
¯¯
• If purging is in progress, the following is displayed
as per below.
• If boost is active, the heat pump status and
temperature T-OFF are displayed as per below.
• If the heat pump is on for Legionella check,
the following is displayed.
• When the heat pump is being turned ON,
during the ON switch time (default 3 seconds),
an upward arrow will blink next to ON.
• When the heat pump is being turned OFF,
during the OFF switch time (3 seconds), a
downward arrow will blink next to ON.
Figure 4-4: Heat pump purging
HEAT PUMP:PURGEHEAT PUMP:PURGE
TANK:56TANK:56
¯¯
Figure 4-5: Heat pump boost on
HEAT PUMP:BOOSTHEAT PUMP:BOOST
TANK:36TANK:36
¯ ¯
TOF:59TOF:59
¯¯
Figure 4-6: Heat pump on for Legionella
HEAT PUMP:ON*HEAT PUMP:ON*
TANK:36TANK:36
¯ ¯
TOF:59TOF:59
¯¯
Figure 4-7: Heat pump 3 seconds ON maintain indicator
HEAT PUMP:ONHEAT PUMP:ON^^
TANK:36TANK:36
¯ ¯
TOF:59TOF:59
¯¯
Figure 4-8: Heat pump 3 seconds ON maintain indicator
HEAT PUMP:ONHEAT PUMP:ON
TANK:36TANK:36
¯ ¯
TOF:59TOF:59
¯¯
