Reclaim Energy | Owners/Installation Manual – Controller v2
28
SECTION
4
4.3 OPERATION MODE
The operation mode selected is displayed, including
when purging is active or when boost is active as shown
below. The following screens shows some examples of
the possible options.
Figure 4-9: Operation mode 1 (24h)
OPERATION MODE 1OPERATION MODE 1
24H24H
Figure 4-14: Operation mode 6 (User timers & temperature)
OP6:10AMN TO 4PMOP6:10AMN TO 4PM
TON:40TON:40
¯ ¯
TOFF:60TOFF:60
¯¯
Figure 4-10: Operation mode 2 (Off-peak 1)
OPERATION MODE 2OPERATION MODE 2
10PM TO 7AM10PM TO 7AM
Figure 4-15: Operation mode 7 (PV default timer)
OPERATION MODE 7OPERATION MODE 7
11AM TO 5PM11AM TO 5PM
Figure 4-11: Operation mode 3 (Off-peak 2)
OPERATION MODE 3OPERATION MODE 3
12AM TO 6AM12AM TO 6AM
Figure 4-16: Purging active
PURGE:ONPURGE:ON
2:27PM-2:32PM2:27PM-2:32PM
Figure 4-12: Operation mode 4 (P.V. connectivity)
OPERATION MODE 4OPERATION MODE 4
10AM TO 4PM10AM TO 4PM
Figure 4-13: Operation mode 5 (User timers)
OP5:1=11PM-5AMOP5:1=11PM-5AM
OP5:2=9AM-12PMOP5:2=9AM-12PM
Figure 4-17: Boost on
BOOST:ONBOOST:ON
2:34PM-8:34PM2:34PM-8:34PM
STATUS DISPLAY CONT.
