RECLAIMENERGY.COM.AU
29
SECTION
DISPLAYED SIGNAL STRENGTH dBm
-50 dBm or greater
Between -70 dBm and -49 dBm
Between -80 dBm and -69 dBm
[blank]
Less than -80 dBm
4
4.4 WIFI STATUS
The Wi-Fi connection status is displayed on this screen
together with the Wi-Fi network name and the Wi-Fi
signal symbol.
4.5 FAULTS
Any faults received from the heat pump and controllerv
are displayed for attention. When a fault has been
detected:
• The fault message will be displayed on the screen
until the fault is cleared.
• The LCD backlight will blink ON/OFF while the fault
is active. It will be turned off when the fault is
cleared.
• The FAULT indicator arrow will blink while the fault is
active. It will be turned off when the fault is cleared.
• The display will not auto-scroll to other status
information while the fault is active.
• The setup menu can still be accessed by pressing the
ENTER key.
The following faults can be displayed:
Figure 4-18: Wi-Fi status
WIFI CONNECTEDWIFI CONNECTED
MyNetwork123MyNetwork123
4.5.1 HEAT PUMP
ERROR
GROUP
ERROR
CODE
MESSAGE
DISPLAYED ON LCD
Eg-1
H9
AMBIENT TEMP
SENSOR ERROR
HC
OUTGOING TEMP
SENSOR ERROR
J3
DISCHARGE TEMP
SENSOR ERROR
J5
SUCTION TEMP
SENSOR ERROR
J6
DEFROST TEMP
SENSOR ERROR
J8
RETURN TEMP
SENSOR ERROR
Eg-2
E6
COMPRESSOR
START ERROR
H6
COMPRESSOR
REVOLUTION ERROR
U0
GAS LEAKAGE
DETECTED ERROR
Eg-3
E1
PCBA MAIN
FAILURE
E2
PCBA CONTROL
FAILURE
E8
INPUT OVER
CURRENT ERROR
F5
PCBA COMMS
ERROR
H8
CURRENT
DETECTION ERROR
L4
MODULE TEMP
ERROR
L5
OUTPUT OVER
CURRENT
P4
MODULE SENSOR
ERROR
U2
POWER VOLTAGE
ERROR
Eg-4
EC
OUTGOING TEMP
WATER ERROR
HJ
CIRCULATION
SYSTEM FAILURE
Eg-5 E9
HEATING
PUMP ERROR
Eg-6 E7
FAN MOTOR
ERROR
Eg-7 F3
DISCHARGE
ERROR
Table 3: List of faults for Heat Pump V2
