FRONT PANEL OPERATION
HEAT PUMP CONTROL V2.0
EXIT
BOOST
ENTER
PWR
TEMP
HP ON
BOOST
FAULT
ERROR
MENUTEMP
59 °C
BOOST key
Normal Mode: Boost Toggle
Menu Mode: Exit Menu
Data Change Mode: Increment
TEMP key
Normal Mode: Sensor °C
Menu Mode: Next Setting
Data Change Mode: Decrement
Green LED : Power
Flashing in standard mode,
Steady on in Boost mode.
Yellow LED : Output
Is telling Heat Pump to turn on.
If flashing is in Boost mode.
Red LED : Fault
LED on solid will display fault
code on digits. Flashing is
sensor fault.
MENU key
Normal Mode: Menu Mode
Menu Mode: Enter
Data Change Mode: Accept setting
