5. Initiate the purge cycle. To activate Purge Mode,
perform the following steps:
a. Ensure the module is in the Normal Display mode,
displaying either Time of day, or Temperature.
b. Press and hold down the Menu button for
approximately 5 seconds.
c. The Display will commence fl ashing “Purg”.
d. The heat Pump output will be disabled.
e. The Purge output will be enabled.
f. Purge mode will remain active for 5 minutes.
g. All menu and display modes are disabled during
Purge Mode.
h. After 5 minutes has elapsed, the purge output will
turn off.
i. All control functionality will resume.
j. When the test operation display above disappears
and the purge mode is complete, open the PTRV
on tank for 5 seconds.
k. When water comes out from the PTRV on tank,
close the PTRV.
Note: Purge mode can be turned off at any time, by
pressing and holding the menu button for 5 seconds.
Purge mode is automatically turned off if the module
is currently displaying a heat pump error code.
6. Select among the 6 operational modes. To see if
the option is selected correctly, after setting up the
option, please go back to the main menu and press
“temp” button. Then, the current tank option and
active option will be shown within seconds.
Owners/Installation Manual – Controller v1.1
Owners/Installation Manual – Controller v1.1
Make sure to complete the air purg before
heating operation. It can cause unit failure
CAUTION
