RECO RM-BV4 Micro DP User Manual

Documentation RM-BV4 Micro DP
RDN 10000662 18 24.01.2014
9 Technical specifications
Item
Data
Terminals
Supply voltage
Device version 230 V AC:
1 (L), 2 (N), 3 (PE)
230 V AC + / -10 %
Device version 110 V AC:
1 (L), 2 (N), 3 (PE)
110 V ... 120 V AC + / -10 %
Device version 24 V DC:
1 (+), 2 (-)
24 V DC +10 % / -0 %
Outputs for
solenoid valves
4 outputs,
24 V DC, max. 1.9 A
9, 10 (Valve 1),
11, 12 (Valve 2),
13, 14 (Valve 3)
15, 16 (Valve 4)
Signal input
1 inputs 24 VDC, to be served potential-free
7, 8
Signal output
1 relay outputs (changeover contact), potential-free
Max. contact rating:
250 V AC, 10 A
50 V DC, 1,5 A / 30 V DC, 10 A (ohmic)
4, 5, 6
∆p measuring range
0 … 5000 Pa
Measuring sensor
piezoresistive
Power consumption
Device version 230 V AC:
0.2 A
Geräte-Version 110 V AC:
0,35 A
Device version 24 V DC:
1,13 A
Fuse
Device version 230 V AC:
T 0.3 A, 250 V, 5 x 20 mm
Device version 110 V AC:
T 0,4 A, 250 V, 5 x 20 mm
Device version 24 V DC:
T 2,5 A, 250 V, 5 x 20 mm
Temperature range
-20 °C ... +60 °C
Protection class
Housing IP66, NEMA 4
Weight
approx. 950 g
Altitude
Max. 3000 m above sea level
Disclaimer
The contents of this documentation have been verified for correctness and completeness. Nevertheless, errors can not be excluded
so that we cannot guarantee the correctness of this information. Subject to alterations at any time.
